Atach Stainless Steel Centrifugal Pumps GZA(S)80-65-200/22

- Name of pump: Stainless steel centrifugal pump GZA(S)80-65-200/22

- Pump Type: Centrifugal Pump

- Pump model:GZA(S)80-65-200/22

- Pump brand: ATACH

-Installation Type: horizontal

- Impeller Quantity: 1 pcs

- Rated pump capacity: 100 m³/h

- Rated pump head: 50 m

- Power/speed: 22 Kw/2900 r.p.m

- Power supply:3 phase/380V/50HZ
(also supply special voltage,special frequency, explosion-proof motor, High efficiency and energy saving motor )

- Material Supply: SUS304,SUS316L

- Shaft Seal: Mechanical seal

- Inlet / outlet : 80mm*65mm

- NPSH: 2 m

- Application:
The pumps are suitable for transporting to stainless steel SUS304 or SUS316.clean media which are non-aggressive

- Mainly applied on:
Water supply systems
Pressure boiler feeding
Pure water treating systems
Refining chemical industries
Washing and sprinkling

- Preformance limits:
Max. Working pressure: 10bar
To avoid overload and danger the pump should be operated within the performance ranges.Media temperature:
With NBR/ceramic/carbon:-20ºC-+80ºC
With Viton/ceramic/carbon:-20ºC-+110ºC
With EPR/ceramic/carbon:-20ºC-+110ºC


If you need other specifications or parameters of DZAS series Stainless steel centrifugal pump, please contact us in detail.
