- Name of pump:ZE(ZAG)250-560 Petrochemical process pump API610 standard OH2 centrifugal
- Pump Type: Centrifugal Pump
- Pump model:ZE(ZAG)250-560
- Pump brand: ATACH
-Installation Type: horizontal coupling
- Impeller Quantity: 1 pcs
- Rated pump capacity: 665 m3/h
- Rated pump head: 57 m
- Power/speed: 160 Kw/1470 r.p.m
- Power supply:3 phase/380V/50HZ
(also supply special voltage,special frequency, explosion-proof motor, High efficiency and energy saving motor )
- Material Supply: stainless steel 316
- Shaft Seal: Mechanical seal
- Inlet / outlet : 250mm*250mm
Product Description:
Capacity: 2-2600m3//h
Head: ~250m
Temperature: -80-350ºC
Application: to deliver various clean or particle-contained inflammable, explosive and strong corrosive media, mainly in the areas of oil refineries, petrochemical, power plants, ordinary industrial processes, marine industries, etc.
ZE series pumps are designed to the standard of API (the 10* edition). The closed and semi-open impellers under this series adopt the balanced axial force with balance hole plus wearing ring, while oper impellers adopt the balanced axial force with back vane. The pump casings of discharge diameter above 80mm are designed into double volute balanced radial force to guarantee the service life of bearing and deflection at shaft seal. According to different working conditions, bearings may be cylindrical roller and angular contact ball bearings or cylindrical roller and tapered roller bearings to greatly improve the service life of bearings.
If you need other specifications or parameters of ZE(ZAG) series Petrochemical process pump, please contact us in detail.
