20 Inch Water Pumps Horizontal Centrifugal Pump Electric Split Case Fire Fighting Pump 500S59/20SH-9

- Name of pump:20 inch water pumps horizontal centrifugal pump electric split case fire fighting pump

- Pump Type: Centrifugal Pump

- Pump model: 500S59/20SH-9

- Pump brand: ATACH

-Installation Type: horizontal coupling

- Impeller Quantity: 1 pcs

- Rated pump capacity: 2020 m3/h

- Rated pump head: 59 m

- Power/speed: 450 Kw/970 r.p.m

- Power supply:3 phase/Voltage as required/50HZ
(also supply special voltage,special frequency, explosion-proof motor, High efficiency and energy saving motor )

- Material Supply: Cast iron

- Shaft Seal: Mechanical seal/packing seal

- Inlet / outlet : 500mm*350mm

- General:
Type S pump is single-stage double suction split-casing centrifugal pump, it pumps clean water and other liquids that their physical and chemical property is similar to clear water.  Type SR (hot water pump), type SM (wearable pump), type SF (corrosion resistant pump) and type SY (oil pump) are designed on the basis of type S by changing the materials and sealing structure etc.  The performance parameters and figure dimensions are the same as the corresponding type S pump.
The serial pump conforms to GB/T5657,the standard of <<Centrifugal Pump Technical Condition III>>.

- Application:
The serial pumps are mainly used for draining or water supply pump in factory, mine, city, power plant, irrigation project, petroleum project etc.

- Working Condition:
Speed:370, 495, 595, 740, 980, 1480, and 2980r/min
Voltage:380V, 6000V, 10000V
Inlet Diameter:150~1400mm
Range of Capacity:160~20000m³/h (Designed point)
Range of Head:12~185m (Designed point)
Range Of Temperature: ≤80ºC(Type SR can reach150ºC by adopting special structure and material)
Permitted Maximum Pressure of Inlet: 0.3MPa
Clean water and other liquids that their physical and chemical property is similar to clear water, solid contents don't exceed 80mg/l: it can pump industrial corrosive waste water, seawater and rainwater including suspend substance etc. when adopting special material.


If you need other specifications or parameters of S/SH series Split Casing Pump, please contact us in detail.
